By Muzammil Shaik 10 min read

GH workflow

github workflow is a way to automate the process of building, testing, and deploying code. It is a set of instructions that you can define in a yaml file. You can define the steps in the workflow and the workflow will run the steps in the order that you define. You can also define the conditions for running the workflow. For example, you can define a workflow to run when a pull request is created or when a push is made to the main branch.

GH workflow syntax

The syntax for a github workflow is defined in a yaml file. The yaml file is a text file that is defined by a set of rules. The rules are defined in the yaml spec.

The following is an example of a yaml file that defines a github workflow.

1
2
3
4
5
6
7
8
9
10
11
12
13

name: my workflow
on:
  push:
    branches:
      - main
jobs:
  my job:
    runs-on: ubuntu-latest
    steps:
      - name: checkout
        uses: actions/checkout@v3
      - name: run a command
        run: echo "hello world"

GH default variables

GitHub provides several built-in contexts to access info dynamically:

1. Workflow & Job Information

Variable Description Usage Example
GITHUB_WORKFLOW The name of the workflow $GITHUB_WORKFLOW
GITHUB_RUN_ID Unique ID for the current run $GITHUB_RUN_ID
GITHUB_RUN_NUMBER The run number of the workflow $GITHUB_RUN_NUMBER
GITHUB_JOB ID of the current job $GITHUB_JOB
GITHUB_ACTION Name of the action currently running $GITHUB_ACTION
GITHUB_ACTIONS Always set to true in GitHub Actions $GITHUB_ACTIONS
GITHUB_ACTOR The user who triggered the workflow $GITHUB_ACTOR
GITHUB_REPOSITORY Repository name (e.g. user/repo) $GITHUB_REPOSITORY
GITHUB_REPOSITORY_OWNER Owner of the repository $GITHUB_REPOSITORY_OWNER
GITHUB_EVENT_NAME Event that triggered the workflow (e.g., push, pull_request) $GITHUB_EVENT_NAME
GITHUB_EVENT_PATH Path to the event payload JSON file $GITHUB_EVENT_PATH
GITHUB_SHA Commit SHA that triggered the workflow $GITHUB_SHA
GITHUB_REF Git ref (branch or tag) $GITHUB_REF
GITHUB_REF_NAME Short name of the ref $GITHUB_REF_NAME
GITHUB_REF_TYPE Type of the ref (branch or tag) $GITHUB_REF_TYPE

2. File & Directory Paths

Variable Description Usage Example
GITHUB_WORKSPACE Directory where the repository is checked out $GITHUB_WORKSPACE
GITHUB_ACTION_PATH Directory path where the GitHub Action is located $GITHUB_ACTION_PATH
GITHUB_ENV File path for setting environment variables in a step echo "FOO=bar" >> $GITHUB_ENV
GITHUB_PATH File path to add values to the PATH variable echo "/custom/bin" >> $GITHUB_PATH

3. Runner & Environment Information

Variable Description Usage Example
RUNNER_NAME Name of the runner executing the job $RUNNER_NAME
RUNNER_OS OS of the runner (e.g., Linux, Windows, macOS) $RUNNER_OS
RUNNER_ARCH Architecture of the runner (e.g., X64, ARM) $RUNNER_ARCH
RUNNER_TEMP Path to a temp directory $RUNNER_TEMP
RUNNER_TOOL_CACHE Tool cache directory for actions/tool caching $RUNNER_TOOL_CACHE

4. GitHub Token & Secrets

Variable Description Usage Example
GITHUB_TOKEN Auto-generated token for the job for API access $GITHUB_TOKEN
secrets.<SECRET> Your custom or org-wide secrets (via GitHub UI) ${{ secrets.MY_SECRET }}

5. Built-in Workflow Contexts

Context Description Example Usage
github Metadata about the repository and event ${{ github.repository }}
env User-defined environment variables ${{ env.ENV_VAR_NAME }}
secrets Encrypted secrets ${{ secrets.MY_SECRET }}
runner Runner metadata ${{ runner.os }}
job Info about current job (e.g., status) ${{ job.status }}
matrix Matrix values for the current job ${{ matrix.node_version }}
strategy Matrix strategy values ${{ strategy.job-index }}
steps Access previous step outputs ${{ steps.step_id.outputs.some_output }}
needs Access outputs from dependent jobs ${{ needs.build.outputs.artifact_url }}
inputs Inputs to reusable workflows or workflow_dispatch ${{ inputs.username }}
vars Repository/organization-level variables ${{ vars.SITE_NAME }}

6. GitHub Actions Triggers

Trigger (on:) Description
push Triggered when a commit is pushed to the repository
pull_request Triggered when a pull request is opened, synchronized, etc.
workflow_dispatch Manual trigger via GitHub UI or API
repository_dispatch Triggered from external systems via API call
schedule Triggers at scheduled times using CRON syntax
check_run Triggered for check runs (create, update, rerequest)
check_suite Triggered for check suites (completed, requested)
create Triggered when a branch or tag is created
delete Triggered when a branch or tag is deleted
deployment Triggered when a deployment is created
deployment_status Triggered when the deployment status changes
discussion Triggered on GitHub Discussions activity (created, edited, etc.)
discussion_comment Triggered when a comment is created or edited in a discussion
fork Triggered when someone forks the repository
gollum Triggered when a wiki page is created or updated
issue_comment Triggered when an issue or pull request comment is created/edited/deleted
issues Triggered on issue activities (open, close, label, etc.)
label Triggered when a label is created, edited, or deleted
member Triggered when a collaborator is added, removed, or changed
merge_group Triggered when a merge group is created (GitHub Merge Queue)
milestone Triggered when a milestone is created, closed, or deleted
page_build Triggered when GitHub Pages is built
project Triggered when a project is created, closed, or reopened
project_card Triggered on changes to project cards
project_column Triggered on changes to project columns
public Triggered when a repository is made public
pull_request_review Triggered when a PR review is submitted
pull_request_review_comment Triggered when a PR review comment is made
pull_request_target Same as pull_request but runs in the context of the base repo
release Triggered on release events (created, published, etc.)
registry_package Triggered when a package is published, updated, or deleted
status Triggered when the status of a commit changes
watch Triggered when someone stars the repository
workflow_call Triggered by another workflow using uses:
workflow_run Triggered when another workflow run finishes
1
2
3
4
5
6

on:
  push:
    branches: [main]
  pull_request:
    types: [opened, reopened, synchronize]
  workflow_dispatch:

GH workflow steps

A github workflow is defined by a set of steps. Each step is defined in a job. A job is a set of steps that run on the same runner. The steps in a job run in the order that you define them.

The following is an example of a job that defines two steps.

1
2
3
4
5
6
7
8
9
10
11
12
13

name: my workflow
on:
  push:
    branches:
      - main
jobs:
  my job:
    runs-on: ubuntu-latest
    steps:
      - name: checkout
        uses: actions/checkout@v3
      - name: run a command
        run: echo "hello world"

GH workflow conditions

You can define conditions for running a workflow. The conditions are defined in the on section of the workflow. The following is an example of a workflow that runs when a pull request is created.

1
2
3
4
5
6
7
8
9
10
11
12
13

name: my workflow
on:
  pull_request:
    branches:
      - main
jobs:
  my job:
    runs-on: ubuntu-latest
    steps:
      - name: checkout
        uses: actions/checkout@v3
      - name: run a command
        run: echo "hello world"

GH workflow outputs

You can define outputs for a workflow. The outputs are defined in the jobs section of the workflow. The following is an example of a workflow that defines an output.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

name: my workflow
on:
  pull_request:
    branches:
      - main
jobs:
  my job:
    runs-on: ubuntu-latest
    steps:
      - name: checkout
        uses: actions/checkout@v3
      - name: run a command
        run: echo "hello world"
    outputs:
      my output:
        value: hello world

GH workflow secrets

You can define secrets for a workflow. The secrets are defined in the jobs section of the workflow. The following is an example of a workflow that defines a secret.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

name: my workflow
on:
  pull_request:
    branches:
      - main
jobs:
  my job:
    runs-on: ubuntu-latest
    steps:
      - name: checkout
        uses: actions/checkout@v3
      - name: run a command
        env:
          MY_SECRET: ${{ secrets.MY_SECRET }}
        run: echo $MY_SECRET

GH workflow events

You can define events for a workflow. The events are defined in the on section of the workflow. The following is an example of a workflow that defines an event.

1
2
3
4
5
6
7
8
9
10
11

name: my workflow
on:
  pull_request:
    branches:
      - main
  push:
    branches:
      - main
  release:
    types:
      - created

GH workflow variables

You can define variables for a workflow. The variables are defined in the jobs section of the workflow. The following is an example of a workflow that defines a variable.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28

name: workflow-variable-demo

on:
  push:
    branches: [main]

jobs:
  build:
    runs-on: ubuntu-latest
    env:
      GLOBAL_MESSAGE: "Hello from the job level"
      BUILD_ENV: "production"

    steps:
      - name: Show job-level variables
        run: |
          echo "GLOBAL_MESSAGE = $GLOBAL_MESSAGE"
          echo "BUILD_ENV = $BUILD_ENV"

      - name: Define step-level variables
        env:
          STEP_MESSAGE: "Hello from the step level"
        run: |
          echo "STEP_MESSAGE = $STEP_MESSAGE"

      - name: Use vars context (requires pre-defined repo/organization variable)
        run: |
          echo "Repository Variable = ${{ vars.MY_REPO_VARIABLE }} "

GH selfhost runners

1
2
3
4
5
6
7
8

useradd runner -m -d /home/runner -s /bin/bash
su runner
mkdir actions-runner && cd actions-runner
curl -o actions-runner-linux-x64-2.325.0.tar.gz -L https://github.com/actions/runner/releases/download/v2.325.0/actions-runner-linux-x64-2.325.0.tar.gz
echo "5020da7139d85c776059f351e0de8fdec753affc9c558e892472d43ebeb518f4  actions-runner-linux-x64-2.325.0.tar.gz" | shasum -a 256 -c
tar xzf ./actions-runner-linux-x64-2.325.0.tar.gz
./config.sh --url https://github.com/$GITHUB_USERNAME/$REPO --token ${{ secrets.PERSONAL_ACCESS_TOKEN }}
./run.sh &

Create a systemd service unit file

1
2

chmod +x /home/runner/run.sh
sudo nano /etc/systemd/system/github-runner.service

1
2
3
4
5
6
7
8
9
10
11
12
13

[Unit]
Description=GitHub Self-Hosted Runner
After=network.target

[Service]
Type=simple
User=runner
WorkingDirectory=/home/runner
ExecStart=/home/runner/run.sh
Restart=always

[Install]
WantedBy=multi-user.target

1
2
3

sudo systemctl daemon-reload
sudo systemctl enable github-runner
sudo systemctl start github-runner

Use this YAML in your workflow file for each job

runs-on: self-hosted

Examples by Use Case

Lint and Test Node.js App

1
2
3
4
5
6
7
8
9
10
11
12
13

name: Node Lint & Test
on: push
jobs:
  lint:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v3
      - uses: actions/setup-node@v3
        with:
          node-version: '18'
      - run: npm ci
      - run: npm run lint
      - run: npm test

Deploy to GitHub Pages

1
2
3
4
5
6
7
8
9
10
11
12
13

name: Deploy Pages
on:
  push:
    branches: [main]
jobs:
  deploy:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v3
      - uses: peaceiris/actions-gh-pages@v3
        with:
          github_token: ${{ secrets.GITHUB_TOKEN }}
          publish_dir: ./public

Cache Dependencies

1
2
3
4
5
6
7

- name: Cache Node Modules
  uses: actions/cache@v3
  with:
    path: ~/.npm
    key: ${{ runner.os }}-node-${{ hashFiles('**/package-lock.json') }}
    restore-keys: |
      ${{ runner.os }}-node-

Python Test Example with Matrix

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

name: Python Tests
on: [push]
jobs:
  test:
    runs-on: ubuntu-latest
    strategy:
      matrix:
        python-version: [3.8, 3.9, 3.10]
    steps:
      - uses: actions/checkout@v3
      - name: Set up Python ${{ matrix.python-version }}
        uses: actions/setup-python@v4
        with:
          python-version: ${{ matrix.python-version }}
      - run: pip install -r requirements.txt
      - run: pytest

Reusable Workflows

Define a reusable workflow:

1
2
3
4
5
6
7
8
9
10
11
12

# .github/workflows/deploy.yml
on:
  workflow_call:
    inputs:
      env:
        required: true
        type: string
jobs:
  deploy:
    runs-on: ubuntu-latest
    steps:
      - run: echo "Deploying to ${{ inputs.env }}"

Call it from another workflow:

1
2
3
4
5

jobs:
  call-deploy:
    uses: ./.github/workflows/deploy.yml
    with:
      env: production

Docker Image Push with Secrets

Handling Secrets

  1. Go to repo Settings → Secrets → Actions
  2. Add new secret (e.g., AWS_ACCESS_KEY)
  3. Use in workflow: env: AWS_ACCESS_KEY_ID: ${{ secrets.AWS_ACCESS_KEY }}
1
2
3
4
5
6
7
8
9
10
11
12

jobs:
  docker:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v3
      - name: Login to Docker Hub
        run: echo "${{ secrets.DOCKER_PASSWORD }}" | docker login -u ${{ secrets.DOCKER_USERNAME }} --password-stdin
      - name: Build & Push
        run: |
          docker build -t myimage:latest .
          docker tag myimage:latest myrepo/myimage:latest
          docker push myrepo/myimage:latest

Matrix Strategy for Multiple Versions

1
2
3
4
5
6
7
8

strategy:
  matrix:
    node: [14, 16, 18]

steps:
  - uses: actions/setup-node@v3
    with:
      node-version: ${{ matrix.node }}

Trigger Other Workflows

1
2
3
4
5
6
7
8
9
10
11
12
13
14

name: Trigger Other Workflow
on:
  push:
    branches: [main]

jobs:
  trigger:
    runs-on: ubuntu-latest
    steps:
      - name: Trigger downstream
        uses: benc-uk/workflow-dispatch@v1
        with:
          workflow: test.yml
          token: ${{ secrets.PERSONAL_ACCESS_TOKEN }}

Useful Resources

Devops
Linux Github
This post is licensed under CC BY 4.0 by the author.
